Ultra-Low HY Series-1 Ton


The best answer for loading and unloading materials directly onto the lift table platform using pallet trucks, carts, or any wheeled vehicle such as forklifts or ATVs. The Ultra Low Profile lift tables can sit as low as 4” off the floor and come with a strong steel ramp for easily wheeling the load onto the platform. Capable of handling loads of up to six thousand pounds, and able to work in tandem with other tables for even greater loads.

Capacity: 1 Ton
Model: HY1005


MODEL HY1001 HY1002 HY1003 HY1004 HY1005
Capacity kg(lb.) 1000 (2200)
Min. Height mm(in.) 85 (3.3)
Max. Height mm(in.) 860 (33.9)
Platform Size mm mm(in.) 1450×1140 (57.1×44.9) 1600×1140 (63×44.9) 1450×800 (57.1×31.5) 1600×800 (63×31.5) 1600×1000 (63×40)
Lift Time (Second) 25-35
Power Pack 110V/50Hz, AC 0.75kW
Net Weight kg(lb.) 357 (785.4) 364 (800.8) 326 (717.2) 332 (730.4) 352 (774.4)


Made from high quality steel, ensuring longevity and reliability throughout their service life. Providing you with the most efficient, reliable and cost-effective lift product in the market today. The HY Ultra Low Profile Lift Table series uses high-quality hydraulics, rounded corners of the tables to prevent injuries, and a myriad of safety features to make sure you and your people can focus on being productive without injuries. The high-quality hydraulic cylinder is encased in a weather-resistant, all steel housing.

Precision velocity fuses on each hydraulic cylinder eliminates platform free-fall. Equipped with an explosion proof valve in the event of a hose rupture, hard chromed pivot points are fitted with lifetime-lubricated bronze bearings or Teflon coated bushings. Outfitted with hinged safety bars for maintenance and backed by a one-year manufacturer warranty, Mayi Industries has you covered!


There are no reviews yet.

Be the first to review “Ultra-Low HY Series-1 Ton”

Your email address will not be published.


EN1570:1999, CE, CSA, ANSI/ASME Certified
Aluminum safety bar to stop descent of platform
Heavy-duty cylinder with explosion-proof valve that slowly descends if tubing ruptures
Intelligent design with rounded corners to prevent injuries
Hinged maintenance bars for safety
Low profile design
Compact table surface
Ultra low design
Steel ramp
Easy to carry power pack and controller
